Machines

astrolab

Our premium models, with the most advanced features on the market, are easy to use. Available in Pressure Profile, with programming of the pressure profiles for the extraction of each coffee, or Multiboiler, with the traditional extraction at 9 bar. It's your choice.

Water boiler

3.5 kW (12 l)

Coffee boiler

3x 1.5 kW (3x 0.5 l)

dimensions (WDH)

1050x630x545mm

Astrolab 3 PP

Multiboiler machine with pressure profiling for the creation, storage and recall of up to 5 pressure profiles on each group. Control by slight movement of the electronic lever. Interface for direct control of the extraction and all functional parameters of the machine.

Color Steel Cups

Multiboiler
Multiboiler system with independent boilers. The astrolab features a pre-heating of the coffee water boilers, granting perfomance and energy saving.

Pressure Profiling
Pressure profiling is when the barista applies a sequence of varied pressures during extraction, allowing to highlight special characteristics of the coffee or blend. The Astrolab allows total control over the pump pressure throughout the entire extraction

Customization
The new Fiamma Configurator gives you the power to create your own masterpiece! Tap into your creativity. Choose your favourite colours, textures, patterns and enjoy deluxe espresso extracted with your unique Astrolab.

all specifications

Color
Steel
Power
5.5 - 9 kW
Voltage
400V~2N
dimensions (WDH)
1050x630x545mm
Weight (kg)
92
Grupos
3
Boilers
multi-boiler
Temperature control
PID
Brew Pilot
Yes
Shot timer
Yes
Counters
Yes
Smart alerts
Yes
Water boiler
3.5 kW (12 l)
Coffee boiler
3x 1.5 kW (3x 0.5 l)
Pump
rotary
Steam wands
2
Cool touch steam wands
Yes
Water tap
2
Water with temperature control
Yes
Programmable water portions
Yes
Automatic cleaning
Yes
Preheated water
Yes
Touchscreen
Yes
Shortcut keys
Yes
E-lever
Yes
Pressure Profiling
3 x 5
Energy saving
sequential heating
Cup warmer
Yes
360º knobs
Optional
LED lights
Yes
customization
Yes
